BANDPASS FILTERS

Solid state transmitters produce frequency emissions which have to be removed by Bandpass Filters. COM-TECH Bandpass Filters are designed to meet all transmission Masks (DVB-T / DVB-T2, ATSC 1.0 / ATSC 3.0, ISDB-T, DAB, etc.). They are also the main components of the Combiners. Product Series:

  • CL Series: Combline. Rack-Shelf
  • FC Series: Folded Combline. Rack-Shelf, Heat Sinks
  • TF Series: Compact TEM Cavity. Heat Sinks, Forced Air Cooling, Liquid Cooling
  • TC Series: TEM Cavity (Heat Sinks, Forced Air Cooling, Liquid Cooling
  • TS Series: TEM Cavity, SIR. Heat Sinks
  • HR Series: Hairpin. Heat Sinks (VHF B.I)
  • HE Series: Hairpin, EVA-Mode. Heat Sinks, Liquid Cooling (VHF B.I)

DESIGNS

COM-TECH Bandpass Filters use several innovative and proprietary Designs, in order to meet the different transmission requirements, such as selectivity, regulation masks,and Adjacency Combination:

  • XLine: Extracted-Pole Elliptical-Response
  • DualCross: Double Cross-Coupling
  • Cross Coupling
  • All-Pole

FEATURES

COM-TECH Bandpass Filters are designed, engineered, and manufactured with cutting-edge technology in order to grant the maximum reliability and the most advanced performances: highest voltage safety margins, lowest insertion loss, maximum compactness, exceptional mechanical stability and durability.

  • Full-Band Tunability
  • Temperature Stabilization
  • DC-Short
  • Output Monitor Probe
  • Modular Connector System
  • SIR (VHF B.III Filters)
  • Hairpin (VHF B.I Filters)
  • EVA-Mode (VHF B.I and FM Filters)
  • 10-Year Warranty

FEATURES

COM-TECH Bandpass Filters are designed, engineered, and manufactured with cutting-edge technology in order to grant the maximum reliability and the most advanced performances: highest voltage safety margins, lowest insertion loss, maximum compactness, exceptional mechanical stability and durability.

  • Full-Band Tunability
  • Temperature Stabilization
  • DC-Short
  • Output Monitor Probe
  • Modular Connector System
  • SIR (VHF B.III)
  • Hairpin (VHF B.I)
  • EVA-Mode (VHF B.I, FM)
  • 10-Year Warranty

OPTIONS

COM-TECH Bandpass Filters can be provided with specific Options to increase maximum operating power. The resulting downsizing allows significant cost and space savings. Furthermore, they have been engineered to be conveniently integrated into Rack-Shelves.

  • Heat Sinks
  • Forced Air Cooling
  • Liquid Cooling
  • Rack-Shelf

RETUNING

COM-TECH offers several options for Retuning of its Bandpass Filters and Combiners, with different levels of autonomy for the Customer. Tuning Instructions and Tools are provided upon request. COM-TECH also offers customized Tuning Training Courses.

  • On-Site Retuning
  • Factory Retuning
  • Substitution Program
  • Customer Retuning
  • Remote Assisted Retuning

CODING

COM-TECH Bandpass Filters use mnemonic codes:
[Product Series: CL, TS…] [No. of Poles: 6, 8…] [Design: XLine, DualCross] [Cavity Size: 50, 110…] [Operating Band: C, B…]

  • Eg. CL6X50C: CL Series, 6-Pole, XLine, 50 mm, UHF
  • Eg. TS8D110B: TS Series, 8-Pole, DualCross, 110 mm, VHF B.III
