FEATURES

  • EVA-Mode Design
  • 1.0 MHz Minimum Channel Spacing
  • Full Band Tunability
  • DC Short
  • Modular Connector System
  • Modular Frame System
  • 10-Year Warranty

OPTIONS

  • Heat Sinks

LINKS

DB Series: 80F

DB2P80F

DB3P80F

No. of Poles / Cavity Size 2-Pole / 80 mm 3-Pole / 80 mm
Modular Connector System 3x PC32 3x PC32
Max RMS Output Power 5.9 kW 5.9 kW
Max RMS Input Power
Default
2.8
1.9 kW
2.0
1.3 kW
2.0
1.8 kW
1.6
1.4 kW
1.2
1.1 kW

DB Series: 120RF

DB2P120RF

DB3P120RF

No. of Poles / Cavity Size 2-Pole / 120 mm 3-Pole / 120 mm
Modular Connector System 3x PC32 3x PC32
Max RMS Output Power 5.9 kW 5.9 kW
Max RMS Input Power
Default
with Heat Sinks
2.8
3.2 kW
3.8 kW
2.0
2.3 kW
2.8 kW
2.0
3.1 kW
3.8 kW
1.6
2.5 kW
3.0 kW
1.2
1.8 kW
2.3 kW

DB Series: 120F

DB2P120F

DB3P120F

No. of Poles / Cavity Size 2-Pole / 120 mm 3-Pole / 120 mm
Modular Connector System 1x PC32   2x PC64 1x PC32   2x PC64
Max RMS Output Power 18.0 kW 18.0 kW
Max RMS Input Power
Default
with Heat Sinks
2.8
3.2 kW
3.8 kW
2.0
2.3 kW
2.8 kW
2.0
3.1 kW
3.8 kW
1.6
2.5 kW
3.0 kW
1.2
1.8 kW
2.3 kW

DB Series: 220RF

DB2P220RF

DB3P220RF

No. of Poles / Cavity Size 2-Pole / 220 mm 3-Pole / 220 mm
Modular Connector System 3x PC32 3x PC32
Max RMS Output Power 5.9 kW 5.9 kW
Max RMS Input Power
Default
with Heat Sinks
2.0
5.1 kW
6.1 kW
1.4
3.7 kW
4.4 kW
2.0
4.6 kW
5.5 kW
1.6
3.6 kW
4.4 kW
1.2
2.7 kW
3.3 kW

DB Series: 220F

DB2P220F

DB3P220F

No. of Poles / Cavity Size 2-Pole / 220 mm 3-Pole / 220 mm
Modular Connector System 1x PC32   2x PC64 1x PC32   2x PC64
Max RMS Output Power 18.0 kW 18.0 kW
Max RMS Input Power
Default
with Heat Sinks
2.0
5.1 kW
6.1 kW
1.4
3.7 kW
4.4 kW
2.0
4.6 kW
5.5 kW
1.6
3.6 kW
4.4 kW
1.2
2.7 kW
3.3 kW
