FEATURES
- 6 and 8-Pole
- 100, 140 and 200 mm Cavity Size
- DualCross: Double Cross Coupling (6 and 8-Pole)
- Adjacent Block Combination
- Full Band Tunability
- Temperature Stabilization
- DC Short
- Interchangeable Connector System
- Modular Frame System
 |
 |
||
DF Series: 100RR |
DF6D100RR |
DF8D100RR |
|
| Order / Cavity Size | 6-Pole DualCross / 100 mm | 8-Pole DualCross / 100 mm | |
| Interchangeable Connector System | 64 mm | 64 mm | |
| Max RMS Output Power | 4.60 kW | 4.60 kW | |
| Max RMS Input Power Default with Heat Sinks |
N.C.M. (Case 2) 1.65 kW 2.05 kW |
C.M. (Case 1) 1.35 kW 1.70 kW |
S.C.M. (Case 3) 1.20 kW 1.50 kW |
|
|
||
DF Series: 100R |
DF6D100R |
DF8D100R |
|
| Order / Cavity Size | 6-Pole DualCross / 100 mm | 8-Pole DualCross / 100 mm | |
| Interchangeable Connector System | 64 mm | 64 mm | |
| Max RMS Output Power | 12.00 kW | 12.00 kW | |
| Max RMS Input Power Default with Heat Sinks with Forced Air Cooling with Liquid Cooling |
N.C.M. (Case 2) 1.65 kW 2.05 kW (N.A.) 5.10 kW |
C.M. (Case 1) 1.35 kW 1.70 kW (N.A.) 4.25 kW |
S.C.M. (Case 3) 1.20 kW 1.50 kW (N.A.) 3.80 kW |
|
|
||
DF Series: 140RR |
DF6D140RR |
DF8D140RR |
|
| Order / Cavity Size | 6-Pole DualCross / 140 mm | 8-Pole DualCross / 140 mm | |
| Interchangeable Connector System | 64 mm | 64 mm | |
| Max RMS Output Power | 4.60 kW | 4.60 kW | |
| Max RMS Input Power Default with Heat Sinks |
N.C.M. (Case 2) 3.45 kW 4.30 kW |
C.M. (Case 1) 2.85 kW 3.55 kW |
S.C.M. (Case 3) 2.55 kW 3.20 kW |
|
|
||
DF Series: 140R |
DF6D140R |
DF8D140R |
|
| Order / Cavity Size | 6-Pole DualCross / 140 mm | 8-Pole DualCross / 140 mm | |
| Interchangeable Connector System | 64 mm | 64 mm | |
| Max RMS Output Power | 12.00 kW | 12.00 kW | |
| Max RMS Input Power Default with Heat Sinks with Forced Air Cooling with Liquid Cooling |
N.C.M. (Case 2) 3.45 kW 4.30 kW 8.60 kW 7.65 kW |
C.M. (Case 1) 2.85 kW 3.55 kW 7.15 kW 6.35 kW |
S.C.M. (Case 3) 2.55 kW 3.20 kW 6.35 kW 5.65 kW |
 |
 |
||
DF Series: 200RR |
DF6D200RR |
DF8D200RR |
|
| Order / Cavity Size | 6-Pole DualCross / 200 mm | 8-Pole DualCross / 200 mm | |
| Interchangeable Connector System | 100 mm | 100 mm | |
| Max RMS Output Power | 12.00 kW | 12.00 kW | |
| Max RMS Input Power Default with Heat Sinks |
N.C.M. (Case 2) 7.20 kW 9.00 kW |
C.M. (Case 1) 6.00 kW 7.50 kW |
S.C.M. (Case 3) 5.35 kW 6.70 kW |
|
|
||
DF Series: 200R |
DF6D200R |
DF8D200R |
|
| Order / Cavity Size | 6-Pole DualCross / 200 mm | 8-Pole DualCross / 200 mm | |
| Interchangeable Connector System | 100 mm | 100 mm | |
| Max RMS Output Power | 33.00 kW | 33.00 kW | |
| Max RMS Input Power Default with Heat Sinks with Forced Air Cooling with Liquid Cooling |
N.C.M. (Case 2) 7.20 kW 9.00 kW 18.05 kW 15.30 kW |
C.M. (Case 1) 6.00 kW 7.50 kW 14.95 kW 12.70 kW |
S.C.M. (Case 3) 5.35 kW 6.70 kW 13.35 kW 11.35 kW |
