FEATURES
- DualCross: Double Cross-Coupling
- 1 Guard-Channel Spacing
- Full-Band Tunability
- Temperature Stabilization
- DC-Short
- Modular Connector System
- Modular Frame System
- 10-Year Warranty
OPTIONS
- Heat Sinks
- Forced Air Cooling
- Liquid Cooling
LINKS
- Combiners Coding
- Starpoint
- Mask-Combiner
SF6D120C |
SF8D120C |
|||||
No. of Poles / Cavity Size | 6-Pole DualCross / 120 mm | 8-Pole DualCross / 120 mm | ||||
Modular Connector System | 3x PC64 | 3x PC64 | ||||
Max RMS Input Power Default with Heat Sinks with Forced Air Cooling with Liquid Cooling |
DVB-T 1.5 kW 2.1 kW 4.1 kW 5.1 kW |
ATSC 1.3 kW 1.8 kW 3.5 kW 4.4 kW |
ISDB-T 1.2 kW 1.7 kW 3.2 kW 4.0 kW |
DVB-T 1.4 kW 2.0 kW 3.8 kW 4.6 kW |
ATSC 1.3 kW 1.9 kW 3.5 kW 4.2 kW |
ISDB-T 1.1 kW 1.6 kW 3.1 kW 3.7 kW |
SF6D170RC |
SF8D170RC |
|||||
No. of Poles / Cavity Size | 6-Pole DualCross / 170 mm | 8-Pole DualCross / 170 mm | ||||
Modular Connector System | 3x PC64 | 3x PC64 | ||||
Max RMS Input Power Default with Heat Sinks |
DVB-T 3.1 kW 4.4 kW |
ATSC 2.7 kW 3.8 kW |
ISDB-T 2.5 kW 3.5 kW |
DVB-T 2.8 kW 4.1 kW |
ATSC 2.6 kW 3.8 kW |
ISDB-T 2.3 kW 3.3 kW |
SF6D170C |
SF8D170C |
|||||
No. of Poles / Cavity Size | 6-Pole DualCross / 170 mm | 8-Pole DualCross / 170 mm | ||||
Modular Connector System | 2x PC64 1x PC100 | 2x PC64 1x PC100 | ||||
Max RMS Input Power Default with Heat Sinks with Forced Air Cooling with Liquid Cooling |
DVB-T 3.1 kW 4.4 kW 8.1 kW 10.2 kW |
ATSC 2.7 kW 3.8 kW 7.0 kW 8.8 kW |
ISDB-T 2.5 kW 3.5 kW 6.4 kW 8.0 kW |
DVB-T 2.8 kW 4.1 kW 7.6 kW 9.1 kW |
ATSC 2.6 kW 3.8 kW 7.0 kW 8.4 kW |
ISDB-T 2.3 kW 3.3 kW 6.1 kW 7.4 kW |
SF6D220RC |
SF8D220RC |
|||||
No. of Poles / Cavity Size | 6-Pole DualCross / 220 mm | 8-Pole DualCross / 220 mm | ||||
Modular Connector System | 3x PC100 | 3x PC100 | ||||
Max RMS Input Power Default with Heat Sinks |
DVB-T 6.2 kW 8.7 kW |
ATSC 5.4 kW 7.5 kW |
ISDB-T 4.9 kW 6.9 kW |
DVB-T 5.8 kW 8.3 kW |
ATSC 5.3 kW 7.7 kW |
ISDB-T 4.7 kW 6.8 kW |
SF6D220C |
SF8D220C |
|||||
No. of Poles / Cavity Size | 6-Pole DualCross / 220 mm | 8-Pole DualCross / 220 mm | ||||
Modular Connector System | 3x PC100 | 3x PC100 | ||||
Max RMS Input Power Default with Heat Sinks with Forced Air Cooling with Liquid Cooling |
DVB-T 6.2 kW 8.7 kW 15.2 kW 17.0 kW |
ATSC 5.4 kW 7.5 kW 13.1 kW 14.7 kW |
ISDB-T 4.9 kW 6.9 kW 12.0 kW 13.5 kW |
DVB-T 5.8 kW 8.3 kW 14.4 kW 15.6 kW |
ATSC 5.3 kW 7.7 kW 13.2 kW 14.3 kW |
ISDB-T 4.7 kW 6.8 kW 11.6 kW 12.6 kW |
